Features:
- Full time NC/NO relay output, compatible with other brand burglar alarm systems such as HONEYWELL, BOSCH, Paradox, GE and DSC, etc.
- Digital frequency conversion.
- Easy alignment with visual LED indicator.
- PC engineering plastic material.
- Professional waterproof design with the rubber seal around.
- Resistant to rain, fog, snow and frost.
- IP degree: IP65
- Adopt microprocessor control(CPU), real digital circuit.
- Built-in automatic adjustable strong light filtering system (up to 50,000 LUX), Good performance against direct sunlight, completely against fluorescent and car light.
- AGC circuit, the detector will automatically increase sensitivity when faced harsh environment.
- Horizontal / vertical optical angle can be easy to adjust.
Technical parameters:
| Model | ABT-40 | |||
| Detecting distance (outdoor) | 40m | |||
| Detecting distance (indoor) | 120m | |||
| Detection method | Simultaneous interruption of 2 infrared beams | |||
| Response speed | 12-250msec | |||
| Alarm output | Switch signal output(NO/NC) | |||
| Power and Voltage | DC12~24V;Â AC11-18V | |||
| Current consumption | 100mA MAX | |||
| Operating temperature | -25?-55? | |||
| Humidity | 95% MAX | |||
| Tamper | NC. 1B contact output?DC26V/0.5AMax. | |||
| IP rating | IP 65 | |||
| Exterior dimension | 80mm*77mm*195mm | |||
| Weight | 1.0kg | |||
