Camera
Image sensor
5 MP CMOS, 1/2.7″ type
Lens focal length
2.8 mm
Maximum aperture
f/1.6
Lens iris type
fixed
Lens focal type
fixed
Field of view
horizontal: 100–110°
vertical: 50–60°
diagonal: 125–135°
DORI distance
- Detection: 65 m
- Observation: 26 m
- Recognition: 13 m
- Identification: 6.5 m
Maximum illumination distance
- IR LED: up to 15 m
Intelligent lighting control automatically adjusts the intensity of IR LEDs in real time to prevent overexposure. This ensures clear visibility of objects at varying distances — whether close to or far from the camera — in low-light conditions.
Signal-to-noise ratio (SNR)
more than 52 dB
Video
Resolution
- 5 MP (2880 × 1620)
- 4 MP (2560 × 1440)
- 3 MP (2304 × 1296)
- 2 MP (1920 × 1080)
- 0.6 MP (1024 × 576)
Frame rate
up to 25 fps
Image rotation
0°, 180°
Video codec
H.265, H.264
Dynamic range
120 dB (True WDR)
Storage
microSD
Camera supports microSD up to 256 GB. The memory card should be Class V30 or faster. The card is not included in the complete set.
Audio
Built-in microphone
With the corresponding settings, the camera can record audio at the scene.
Audio codec
G711-ULAW, G711-ALAW, G726, G722
Intelligent video analytics
Motion detection
The camera detects motion using software image frame analysis.
AI object detection
People
Pets
Vehicles
Smart IR illumination
up to 15 m
Automatic adjustment of intensity in real time to avoid overexposure. This allows you to see objects that are far away or too close to the camera in low light conditions.
Network
Port
1 × RJ-45 self-adaptive Ethernet (10/100 Mbps)
Protocol
HTTP, HTTPS, TCP/IP, IPv4, IPv6, SNMP, RTSP, UDP, DHCP, DNS, DDNS
ONVIF®
conformant with ONVIF® Profile G and S
The device implements ONVIF® H.265 (HEVC) encoding, transmission of motion detection and AI recognition events, control over Wide Dynamic Range (WDR), and other image settings — not ONVIF® profile or add-on conformant.
