- Identification of up to 10,000 faces with face liveness detection*.
- 3.5” touchscreen display.
- TCP / IP, USB, Wi-Fi* and Bluetooth* connectivity.
- Integrated SIP intercom*.
- Customised access rules according to groups and schedules.
- IP65 ingress protection rating.
- (* Available on select models).
| Technical Specifications | |
| Access Control | |
| Number of Users | More than 200,000 registered users |
| Number of Faces | Up to 10,000 faces with face liveness detection * |
| Access Rules | Access rules according to schedules and departments |
| Door Control | 1 door with REX button and door sensor inputs |
| Relay Output | 1 relay rated up to 30 VAC / 5 A |
| Wiegand Input | 1 native port |
| Wiegand Output | 1 native port |
| * Available on select models | |
| Communication | |
| Ethernet | 1 native 10 / 100 Mbps Ethernet port |
| USB | 1 USB 2.0 Host Port |
| RS-485 | 1 RS-485 port for communication between the external access control module and terminal |
| Wi-Fi | Integrated Wi-Fi connectivity (optional) |
| GPRS | Optional GPRS module |
| SIP Intercom | Integrated SIP intercom (Pro) |
| Identification Methods | |
| Facial Identification | Two 1080p Full HD cameras (visible light and infrared light) |
| Proximity Cards (optional) | MIFARE TM or 125 kHz ASK or HID |
| Password | User identification through PIN and password |
| QR Code | User identification through QR Code |
| User Interface | |
| LCD Touchscreen | 3.5” TFT Colour LCD Display (320 × 480) with Capacitive Touchscreen |
| Integrated Web Software | Complete access control management from your browser |
| Audio | Built-in speaker and microphone |
| General Characteristics | |
| General Dimensions | 76.7 mm × 54.5 mm × 174 mm (W × D × H) – Terminal 52 mm × 52 mm × 22 mm (W × D × H) – External Access Control Module |
| Equipment Weight | 240 g – Terminal 35 g – External Access Control Module |
| Power Input | External 12 V 2 A source |
| Ingress Protection Rating | IP65 |
| International Certifications | |
| Certifications | CE, FCC, UKCA and ISED (available on select models) |
