Description

• High quality imaging with 2 MP, 1920 × 1080 resolution
• 2.8 mm, 3.6 mm fixed focal lens
• Up to 20 m IR distance for bright night imaging
• Up to 20 m white light distance for bright night imaging
• One port for four switchable signals (TVI/AHD/CVI/CVBS）
• Water and dust resistant (IP66)
• High quality audio with audio over coaxial cable, built-in microphone
• Smart-Hybrid light, optimize your security with flexible lighting options

• Camera
• Image Sensor2 MP CMOS
• Max. Resolution1920 (H) × 1080 (V)
• Min. Illumination0.01 Lux @ (F2.0, AGC ON), 0 Lux with IR
• Shutter TimePAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
• Day & NightICR
• Angle AdjustmentPan: 0 to 360°, tilt: 0 to 180°, rotate: 0 to 360°
• Signal SystemPAL/NTSC

• Lens
• Lens TypeFixed focal lens, 2.8 mm and 3.6 mm optional
• Focal Length & FOV

  2.8 mm, horizontal FOV: 100°, vertical FOV: 55°, diagonal FOV: 116°

  3.6 mm, horizontal FOV: 80°, vertical FOV: 43°, diagonal FOV: 95°

• Lens MountM12

• Microphone
• Pickup DistanceIn a radius of up to 5 m
• Amount1

• Illuminator
• Supplement Light Range

  IR : up to 20 m

  White Light : up to 20 m

• Supplement Light TypeSmart, IR, White Light

• Image
• Image SettingsBrightness, Sharpness, Smart IR
• Frame Rate

  TVI: 1080P @30 fps, 1080P @25 fps

  AHD: 1080P @30 fps, 1080P@25 fps

  CVI: 1080P @30 fps, 1080P @25 fps

  CVBS: PAL/NTSC

• Wide Dynamic Range (WDR)Digital WDR
• Image EnhancementDWDR/BLC/HLC/Global
• White BalanceAuto/Manual
• AGCYes
• Day/Night ModeAuto/Color

• Interface
• Video OutputSwitchable TVI/AHD/CVI/CVBS

• General
• MaterialPlastic
• DimensionØ70 mm × 153.4 mm (Ø2.76″ × 6.04″)
• WeightApprox. 164 g (0.36 lb)
• Operating Condition-40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensation)
• CommunicationHIKVISION-C
• LanguageEnglish
• Power Supply

  12 VDC ± 25%

  *You are recommended to use one power adapter to supply the power for one camera.

• ConsumptionMax. 3.2 W

• Approval
• ProtectionIP66
