| Camera Image Sensor |
2 MP CMOS |
| Signal System |
PAL/NTSC |
| Resolution |
1920 (H) × 1080 (V) |
| Frame Rate |
TVI: 1080p @ 25 fps/30 fps |
| Min. Illumination |
0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Time |
PAL: 1/25 s to 1/50,000 s<br>NTSC: 1/30 s to 1/50,000 s |
| Slow Shutter |
Max. 16 times |
| Lens |
2.8 mm, 3.6 mm, 6 mm fixed focal lens |
| Field of View |
2.8 mm: Horizontal FOV: 98°, Vertical FOV: 52°, Diagonal FOV: 116°<br>3.6 mm: Horizontal FOV: 77°, Vertical FOV: 42°, Diagonal FOV: 91°<br>6 mm: Horizontal FOV: 51°, Vertical FOV: 28°, Diagonal FOV: 59° |
| Lens Mount |
M12 |
| Light Alarm |
Flashing Light Alarm (Red & Blue) |
| Day & Night |
Colour |
| WDR (Wide Dynamic Range) |
≥130 dB |
| Angle Adjustment |
Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360° |
| Menu |
White Light Auto/Off<br>Image Mode: STD/HIGH-SAT/HIGHLIGHT |
| AGC |
Yes |
| Day/Night Mode |
Colour |
| White Balance |
Auto/Manual |
| AE (Auto Exposure) Mode |
WDR, BLC, HLC, Global, HLS |
| Privacy Mask |
4 programmable privacy masks |
| Motion Detection |
4 programmable motion areas |
| Noise Reduction |
3D DNR/2D DNR |
| Language |
English |
| Function |
Brightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Anti-Banding, Smart Light |
| Interface |
Video Output: 1 HD analog output<br>Alarm: 1 line out<br>Audio In: Built-in mic |
| General Operating Conditions |
-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%<br>*You are recommended to use one power adapter to supply the power for one camera. |
| Consumption |
Max. 11.4 W |
| Protection Level |
IP67 |
| Material |
Front cover: Metal, Main body: Plastic |
| White Light Range |
Up to 40 m |
| PIR Range |
Angle: 110°, Range: 11 m |
| Communication |
HIKVISION-C |
| Dimension |
82.6 mm × 77.1 mm × 213.2 mm (3.25″ × 3.04″ × 8.39″) |
| Weight |
Approx. 467 g (1.03 lb.) |
