Camera module that works with our newly released wireless
outdoor Tri-tech detector, built-in CMOS high quality color
camera that provide you an ideal solution for video
verification, both users and CMS can verify alarms day and
night by viewing real-time images captured by this camera
module for fast and accurate response to real alarm events
1/2.7″ Progressive Scan CMOS
2.0 mm fixed lens
3D Digital Noise Reduction
Easy Installation
The direction of the Angle can be adjusted to fit the TT
Detector’s Angle
Protection Level IP66
Specification
Detection Performance
Detection Method Video Verification
Feature
Digital Noise Reduction 3D
Focal length 2.0mm@F2.25
Video
Field Angle 137.2°(H), 80.1°(V)
Image Type JPEG
Resolution 640*480,320*240,160*120
Fill Light Infrared Light
Fill Range 15m
Day/Night Switch Auto
Interface
Communication Interface 1 12-Bit Data Interface
Electrical Characteristics
Power Supply 3 VDC
Power Consumption 1200mA
General
Operation Temperature -25 °C to 60 °C (-13 °F to 140 °F)
Storage Temperature -25 °C to 60 °C (-13 °F to 140 °F)
Operation Humidity 10% to 90%
IP Rate IP66
Dimension(WxHxD) 74.1mm x 72.35mm x 53mm
Weight 155g
