HiLook by Hikvision 16ch Turbo HD kit - DVR - 16 x HD720P Camera - 20M Night vision - 1TB HD - 100m Cable

R9,495.00

Kit Includes

1 x HiLook DVR-116Q-F1 16 channel TVI 1080P Lite Hydrid DVR With Smartphone and PC viewing
16 x HiLook THCB110: 1 MP EXIR Bullet Camera, 20m IR Distance, IP66
1 x 1TB SATA Hard Drive
32 x BNC Plug
16 x DC plugs
1 x 12VDC 30A Power Supply
1 x 100m Cable RG59 Co-Axial
No Screen

 1 MP high-performance CMOS 

 1296 × 732 resolution 

 2.8 mm, 3.6 mm, 6 mm fixed focal lens 

 Day/Night switch 

 EXIR 2.0, smart IR, up to 20 m IR distance

 Switchable TVI/AHD/CVI/CVBS 

 IP66



DVR-116G-F1Turbo HD DVR

Easy connection to your mobile with Hikvision Hik-connect bar code scanning, without any technical or port forwarding knowledge. Includes free iPhone, android, PC and Mac remote viewing software

Connectable to Turbo HD/HDCVI/AHD/CVBS signal input
Long distance transmission over UTP and coaxial cable
One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports 1080p lite and when enabled, the image effect is similar with 1080p
Simultaneous HDMI/VGA output at up to 1920 × 1080 resolution
One SATA interface (up to 6 TB capacity per HDD)
Smart search for efficient playback

Video/Audio Input
Audio Input: 1-ch
Video Compression: H.264,H.264+
Analog Video Input: 16-ch
Analog and HD-TVI video input: Support HDTVI input: 1080p25, 1080p30, 720p25, 720p30
Supported camera types: Support AHD input: 1080p25, 1080p30, 720p25, 720p30
Support CVI input: 1080p25, 1080p30, 720p25, 720p30
Support CVBS input
IP Video Input: 2-ch Up to 960P resolution
Video Input Interface: BNC (1.0 Vp-p, 75Ω)
Audio Compression: G.711u
Audio Input Interface: RCA (2.0 Vp-p, 1 kΩ)
Two-way Audio: 1-ch RCA(2.0Vp-p, 1kΩ)
Video/Audio Output
HDMI/VGA Output: 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Recording resolution: When 1080p Lite mode not enabled: 720p/VGA/WD1/4CIF/CIF;
When 1080p Lite mode enabled: 1080p lite/720p lite/VGA/WD1/4CIF/CIF
Frame Rate: Main stream:
When 1080p lite mode enabled:
1080p lite/HD 720p lite/WD1/4CIF/VGA@12fps;
CIF@25fps (P)/30fps (N)
When 1080p lite mode not enabled:
For 720p stream access:
720p/WD1/4CIF/VGA@12fps; CIF@25fps (P)/30fps (N)
For SD stream access:
WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video Bit Rate: 32 Kbps ~ 4 Mbps
Stream Type: Video/Video&Audio
Audio Output: 1-ch RCA(Linear, 1kΩ)
Dual Stream: Support
Synchronous Playback: 16-ch
Network management
Remote connections: 128
Network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP?, HTTPS
Hard Disk Driver
Interface Type: 1 SATA Interface
Capacity: Up to 6 TB capacity for each disk
External Interface
Network Interface: 1; 10M / 100M self-adaptive Ethernet interface
USB Interface: 2 USB 2.0 Interfaces
