Hikvision 8ch 5MP Turbo HD kit - HD DVR up to 8MP - 8 x HD 5MP cameras - 1TB HDD - 100m Cable - 20m Night vision

R13,499.00

Kit Includes

1 x Hikvision DS-7208HUHI-K1 8Ch TURBO HD Embedded DVR.• Support H.265 Pro+/H.265 Pro/H.265 video compression.  With Smartphone and PC viewing
8 x Hikvision DS-2CE16H0T-ITF 5MP bullet camera, 20m IR

1 x 1TB SATA Hard Drive
16 x BNC Plug 3Pcs
8 x DC plugs
1 x 12VDC 10A Power Supply
1 x 100m Cable RG59 Co-Axial
No Screen





5 MP Bullet Camera

•    5 Megapixel high-performance CMOS

•    Analog HD output, up to 5MP resolution

•    True Day/Night

•    OSD menu, 2D DNR, DWDR

•    EXIR technology, up to 20m IR distance

•    IP67

•   4 in 1 video output (switchable TVI/AHD/CVI/CVBS)

•    Up the Coax(HIKVISION-C)

Image Sensor: 5MP CMOS Image Sensor
Effective Pixels: 2560 (H) × 1944 (V)
Shutter Time: 1/25(1/30) s to 1/50,000 s
Lens Mount: M12
Adjustment Range: Pan: 0° to 360°; Tilt:0° to 180°; Rotate: 0° to 360°
Day& Night: IR cut filter with auto switch
Video Frame Rate: 2560 × 1944 @ 20fps
HD Video Output: 1 Analog HD output
Synchronization: Internal Synchronization
Menu
D/N Mode: Auto / Color / B/W
White Balance: Auto/MWB
BLC: Support
Language: English
General
Operating Conditions: -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDC±25%
Weather Proof: IP67
IR Range: Up to 20m
Communication : Up the coax
Protocol: HIKVISION-C(Coaxitron)
Dimension: 58 mm × 61 mm × 163 mm (2.28″ × 2.40″ × 6.42″)
Weight: Approx. 335 g (0.74 lb.)





Hikvision 8ch Turbo HD DVR up to 5MP, H.264 with 4 audio inputs



DS-/7208/S Turbo HD DVR

• H.264+ & Dual-stream video compression
• Support HD-TVI/analog/AHD/IP camera triple hybrid
• Support both HD-TVI and analog cameras with
adaptive access
• Full channel@5MP resolution non real-time recording
• HDMI output at up to 4K while VGA output at up to 1920×1080P
resolution
• Long transmission distance over coax cable
• Support up to 4/8-ch synchronous playback



Video/Audio Input
Audio Input: 4-ch
Video Compression: H.264,H.264+
Analog and HD-TVI video input: 8-ch,BNC interface (1.0Vp-p, 75 Ω)connection
Supported camera types: Support HDTVI input: 5MP,4MP,3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz,
Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz
Support CVBS input
Video Input Interface: BNC (1.0 Vp-p, 75Ω)
Audio Compression: G.711u
Audio Input Interface: 4-ch, RCA (2.0 Vp-p, 1 KΩ)
Two-way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input)
Video/Audio Output
CVBS Output: 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704×576,NTSC:704×480
HDMI/VGA Output: HDMI: 1-ch,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz, 1920×1080/60Hz, 1280×1024/60Hz,1280×720/60Hz,1024 ×768/60Hz
VGA:1-ch,2K(2560×1440)/60Hz,1920×1080/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz
Recording resolution: Mainstream:5MP/4MP/3Mp/1080p/720p/WD1/4CIF/VGA/CIF
Sub-stream:WD1/4CIF/CIF/QVGA/QCIF
Frame Rate: Main stream:
5MP@10fps/4MP@15fps/3MP@15fps/1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps;CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video Bit Rate: 32 Kbps-10 Mbps
Stream Type: Video/Video&Audio
Two-way Audio: 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
Audio Output: 1-ch RCA(Linear, 1kΩ)
Audio Bit Rate: 64kbps
Dual Stream: Support
Playback Resolution: 5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF/QVGA/QCIF
Synchronous Playback: 8-ch
Network management
Remote connections: 128
Network protocols: TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,ONVIF
Hard Disk Driver
Interface Type: 2 SATA Interfaces
Capacity: Up to 6 TB capacity for each disk
External Interface
Network Interface: 1; 10M / 100M / 1000M self-adaptive Ethernet interface
USB Interface: 1 USB 2.0 Interface & 1 USB 3.0 Interface
Serial Interface: 1; standard RS-485 serial interface, half-duplex
Alarm Input: 8-ch
Alarm Output: 4-ch
General
Power Supply: 12 VDC
Consumption: ≤ 20W(without hard disks)
Working Temperature: -10 oC to +55 oC (14 oF to 131 oF)
Working Humidity: 10% to 90%
Chassis: 380mm 1U chassis
Dimensions: 380 × 320 × 48 mm (15.0 × 12.6 × 1.9 inch)
Weight: ≤ 2 kg (4.4 lb)
